Description

Key Features:

• • Improves Taste & Consistency: Reduces chlorine, sediment, cysts, and bacteria for clean, clear beverages

  • High Capacity: Filters up to 35,000 gallons

  • Fast Flow Rate: Up to 3.34 GPM (12.6 LPM)

  • IMPACT Technology: Combines membrane and carbon block for extended performance

  • Built-in Bacteria Inhibitor: Helps reduce fouling and preserve media integrity

  • Quick Change Design: Tool-free cartridge swaps with 1/4 turn

  • Includes Gauge & Shut-Off Valve: For easy monitoring and maintenance

  • NSF Certified & FDA Compliant Materials

Specifications:

• Application: Cold Beverage

• Flow Rate: 3.34 GPM (12.6 LPM)

• Capacity: 35,000 gallons (132,489 liters)

• Inlet/Outlet: 1/2” FNPT horizontal

• Operating Pressure: Max 125 psi (862 kPa)

• Operating Temperature: Max 100°F (37.8°C)

• Cartridge Type: O-ring seal, SQC-style (HF60)

• Certifications: NSF 42 and 53, FDA CFR-21 compliant

• Shipping Weight: 4.1 lbs.

• Operating Weight: 7.5 lbs.

• Case Quantity: 1 system

SPEC SHEET

Installation Notes:

• Install on cold water lines only

• Follow all local plumbing codes

• Protect from freezing and avoid hot water applications

• Use a pressure-limiting valve if pressure exceeds 80 psi

• Replace cartridge every 12 months or at capacity

Changing Your Filter:
