Description

3M ICE190-S Water Filtration System – Powerful Filtration for Commercial Ice Clarity and Equipment Protection

Deliver crystal-clear ice and protect your commercial ice machine with the 3M ICE190-S Water Filtration System. Designed for high-volume ice production environments, this advanced filtration system reduces particulate, chlorine taste and odor, cysts, bacteria, and scale. With an impressive capacity of up to 54,000 gallons and a flow rate of 5 gallons per minute, the ICE190-S is perfect for foodservice establishments that demand quality and reliability.

At the heart of this system is 3M’s IMPACT Technology, a dual-zone filtration media that combines membrane filtration and activated carbon. This innovative design enhances filtration efficiency and extends cartridge life. A built-in scale inhibitor works to prevent calcium and magnesium buildup on ice machine evaporator plates—minimizing downtime and extending equipment life.

For fast and sanitary maintenance, the ICE190-S features a Sanitary Quick Change (SQC) design that allows for quick 1/4-turn cartridge replacements without tools. The system includes a pressure gauge, inlet shut-off valve, and a convenient mounting bracket for easy installation.

Key Features:

• High-Capacity Filtration – Filters up to 54,000 gallons (204,412 liters)

• Fast Flow Rate – Supports up to 5 GPM (18.9 LPM) for large ice machines

• Superior Contaminant Reduction – Reduces chlorine, sediment, cysts, and bacteria for cleaner, better-tasting ice

• Scale Inhibition – Prevents hard mineral deposits on evaporator plates

• IMPACT Dual-Zone Media – Membrane + carbon block for extended performance

• Quick, Tool-Free Cartridge Changes – SQC design with 1/4-turn replacement

• NSF Certified – Complies with NSF Standards 42 & 53 and FDA CFR-21

• Durable 1/2” FNPT Horizontal Ports – Easy installation into commercial plumbing

Specifications:

• Model: 3M ICE190-S

• Application: Commercial ice machine filtration

• Capacity: 54,000 gallons (204,412 liters)

• Flow Rate: Up to 5 GPM (18.9 LPM)

• Filter Media: HF90-S cartridge (carbon block, membrane, scale inhibitor)

• Inlet/Outlet: 1/2” FNPT horizontal ports

• Operating Pressure: Max 125 psi (862 kPa)

• Operating Temperature: Max 100°F (37.8°C)

• Service Life: Replace every 12 months, at capacity, or when flow decreases

• Includes: Head assembly, mounting bracket, pressure gauge, shut-off valve, filter cartridge

Spec Sheet

Installation Notes:

• For use on cold water lines only

• Protect from freezing temperatures

• Uses HF90-S replacement cartridge

• Install a pressure-limiting valve if supply exceeds 80 psi

• Must follow all local plumbing codes

• Replace cartridge every 12 months, at rated capacity, or when flow rate drops.
